PREXISO PDMX-113C Digital Multimeter

PREXISO PDMX-113C Digital Multimeter

Features

• Manual/auto power off
• Be accurate in testing AC/DC Voltage, AC/DC Current, Resistance, Capacitance, Circuit continuity and frequency/duty
• Support diode and on/off test
• Convenient features like NCV and Live test
• Conductivity detection with buzzer
• Pocket size and support data hold
• Easy use in dark environment with backlight and flashlight function
• *Batteries are not included and are sold separately

Specifications

Package	Color Box
Battery	2 × AAA, 1.5V
KT-temperature range	-20℃ to 1000℃(-4℉ to 1832℉)
Resistance(Accuracy)	600Ω/6KΩ/60KΩ/600KΩ/6MΩ/60MΩ/±(1.0%+3)
AC Current(Accuracy)	600μA/6000μA/60mA/600mA/6A/10A/(±(1.5%+3))
DC Current(Accuracy)	600μA/6000μA/60mA/600mA/6A/10A/(±(1.2%+3))
AC Voltage range(Accuracy)	600mV/6V/60V/600V/(±(1.0%+3))
DC Voltage range(Accuracy)	600mV/6V/60V/600V/(±(0.5%+3))
Max voltage	600V AC/DC
